Oil Immersed Transformer

What is Oil Immersed Transformer?

Oil immersed transformers use insulating oil as the medium for insulation and cooling. The insulating oil covers the windings and the core, capable of absorbing the heat generated during the operation of the equipment. This heat is then dissipated into the air through natural convection or by means of fans. When used as the main transformer, a large-capacity transformer is usually of the oil immersed type.

Benefits of Oil Immersed Transformer1.Strong heat dissipation capability

Insulating oil has a high specific heat capacity, enabling it to absorb and store large amounts of heat. This ensures that heat generated during equipment operation is evenly dissipated, preventing overheating and its associated effects.

2.Strong insulation performance

Transformer oil has a high dielectric strength, allowing it to fully integrate with insulating paper to enhance insulation strength.

3.Strong overload capacity

Oil-immersed transformers can withstand loads exceeding their rated capacity for short periods of time. The temperature of the oil rises relatively slowly, providing a buffer for the load.

4.Strong protective capabilities

Insulating oil covers the internal components of the transformer, preventing them from coming into contact with air and extending the service life of the equipment.

5.Excellent arc-quenching performance

Insulating oil decomposes at high temperatures to produce gases with arc-quenching capabilities, which can quickly extinguish arcs.

6.Cost effective

Under the same capacity, oil-immersed transformers have lower manufacturing costs and lower no-load losses.

Core components of oil immersed transformer

Insulating oil

Insulating and cooling medium for transformers, meeting the standard of a breakdown voltage greater than 40KV.

Core

A closed magnetic circuit formed by laminated silicon steel sheets, which reduces logistics losses.

Windings

High/low-voltage coils made of copper or aluminum wires, with each turn wrapped in insulating paper.

Oil tank

Holds the insulating oil, windings, and core; a sealed container that prevents external air ingress.

Radiator

Radiators and fins are typically installed on the oil tank to increase the heat dissipation area and achieve better heat dissipation.

Oil reservoir

Regulates oil volume, reduces oil oxidation, and isolates air.

Bushing

Made of ceramic or composite insulators, it leads the winding leads out of the oil tank. Low-voltage bushings are typically smaller than high-voltage bushings.

Relay

Monitors gases in the oil and issues an alarm in case of a fault.

Pressure Relief Valve

Can quickly release internal pressure during operation to prevent bursting due to excessive local pressure.

Oil Level Gauge/Oil Temperature Gauge

Allows operators to clearly observe changes in oil temperature and monitor oil conditions, enabling proactive troubleshooting.

View as

35kV On Load Regulator Transformer

Lugao Power Co., Ltd transformers have been successful in many countries in Central Asia and Africa, selling more than 100 units per year to foreign countries for use in substations, power plants, etc. Minimum order for 35kv On Load Regulator Transformer is 1 unit, which can be completed within 2 weeks. LUGAO also has Distribution Transformer in stock to respond to customer needs in a timely manner.

View More >> Send Inquiry >>

11kV To 0.4kV Step Down Oil Type Industrial Transformer

Lugao Power Co., Ltd's transformers have been exported to multiple countries, involving substation projects and urban power supply areas. During transportation, export-specific wooden crates are used, and the transformers are securely fastened in place. The 11kV To 0.4kV Step Down Oil Type Industrial Transformer utilizes the principle of electromagnetic induction to convert high voltage into suitable low voltage, which is then transmitted to the designated area. LUGAO's transformers have passed a series of international standards, such as CE and ISO.

View More >> Send Inquiry >>

High Voltage 10-35kv Aluminum Winding Oil Transformer

Lugao Power Co., Ltd has a long experience in the field of transformers, and many years of experience in manufacturing has allowed Lugao to develop deep relationships with customers in many countries.High Voltage 10-35kv Aluminum Winding Oil Transformer uses economical and lightweight aluminum windings, and the material costs have been reduced. The use of economical and lightweight aluminum windings reduces material costs, facilitates installation, and reduces transportation costs.

View More >> Send Inquiry >>

630KVA 10kv Automatic Low Loss Oil Type Transformer

Lugao Power Co., Ltd's transformers are designed with a focus on loss reduction. 630KVA 10KV Automatic low loss oil type transformer uses transformer oil as the insulation and heat dissipation medium. LUGAO can customize the transformer according to the customer's requirements, including voltage level, capacity, material, etc. LUGAO can also customize the transformer according to the customer's requirements.

View More >> Send Inquiry >>

Outdoor Threephase Oil Immersed Electric Transformer

As a professional transformer manufacturer, Lugao Power Co., Ltd. exports more than one hundred transformers to overseas every year. Lugao has a set of professional production line, and the annual output can be up to one thousand units. high-performance Outdoor Threephase Oil Immersed Electric Transformer is sold to overseas every month, no matter it is seaside or high altitude area. This transformer is suitable for both seaside and high altitude areas.

View More >> Send Inquiry >>

10KV All Copper Oil Immersed Power Transformer

Lugao Power Co., Ltd has been plowing into the field of transformers for many years, over the years LUGAO with excellent product quality has been professional service level, with customers in many countries to reach a deep cooperative relationship. LUGAO has been highly evaluated by our customers after visiting our factories.S13 10KV all copper oil immersed power transformer is designed according to the requirements and suggestions of our customers.

View More >> Send Inquiry >>

The professional China Oil Immersed Transformer manufacturer and supplier, we have own factory. We will give you the satisfactory quotation. Let us cooperate with each other to create a better future and mutual benefit.
