Lugao Power Co.,Ltd is a company specializing in R&D, Production and sales of high voltage transmission and distribution equipment. A ring main unit is a fully insulated, fully sealed, maintenance-free vacuum switchgear device that integrates a vacuum arc extinguishing chamber, main electrical circuit, and insulating supports into a single unit. The functional units are connected via fully insulated solid busbars. The overall structure is simple, easy to install, and operates unaffected by external environmental conditions, making it suitable for urban residential distribution.
1. High safety
Touchable parts are shielded to prevent electric shock accidents. A comprehensive interlocking system ensures clear visibility of the three-phase isolation break, minimizing the risk of operational errors. The vacuum arc extinguishing chamber features explosion-proof performance, and the switch housing provides additional protective functionality.
2. Easy to Operate
The isolating switch and grounding switch have only one operating handle, eliminating the risk of errors. The operating procedure is straightforward, and even personnel with basic electrical knowledge can operate it without the need for complex training.
3. Environmentally Friendly and Non Toxic
The manufacturing materials are non-toxic and harmless, and no harmful substances are produced during use. The materials are also recyclable.
4. Convenient installation and transportation
The entire product series is uniformly designed, offering users various cabinet types with consistent external dimensions. They can be assembled on site, expanded as needed, and quickly put into use.
5. Maintenance free
Except for the operating mechanism, the high voltage switch portion of the solid insulated indoor AC high voltage vacuum switchgear is in a completely sealed state, reducing operational maintenance costs and eliminating the need for cleaning.
Taking the XGN15-12 cabinet type as an example
Cabinet structure
The cabinet is constructed using 2mm thick aluminum-zinc-coated steel plates riveted into shape. The rear of the cabinet features pressure relief holes, with one connecting to the cable compartment and the other to the busbar compartment.
Busbar compartment
Located at the top of the cabinet and connected to adjacent switchgear cabinets, the load switch is an independent unit filled with SF6 gas.
Cable compartment
Used for connecting cables, installing fuses, grounding switches, and CT/PT transformers.
Circuit breaker compartment
SF6 circuit breakers or vacuum circuit breakers are installed below the load switch.
Operating mechanism and interlocking
Includes the operating mechanism, interlocking devices, position indicators, auxiliary contacts, and live display indicators.
